Universal Pipe Cutting Machine SA983C020 for Precision Cutting Applications

Manual Metal Lathes

Manufacturer: SASTA PJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

Universal pipe cutting machine CA983C010 Universal pipe cutting machine CA983C030

Description

- Universal pipe cutting machine CA983C020 - specialised equipment designed for processing pipe joints can also be used for all types of turning operations.
Easy to use pipe cutting machine designed for processing long pipes and pipe joint parts with diameter up to 340 mm, used for oil and natural gas production and transportation.
It is also suitable for all types of turning operations, including cutting metric and inch threads, including tapered threads.
Equipped with a hydraulic mechanism for automating a single threading pass (hydro-bounce) when threading in both manual and cycle mode.

Specifications

Type of product according to PP RF 616

Turning and screw-cutting machines (universal, with CNC, CNC)

Length

4640 mm

Width

2050 mm

Height

1675 mm

Weight

10900 kg

The largest diameter of the workpiece, to be mounted above the bed

830 mm

The largest diameter of the workpiece, to be machined above the slide

450 mm

Maximum length of workpiece to be machined with tapered ruler

500 mm

Z-axis travel (longitudinal movement of the slide)

2000 mm

Pitch limit of the thread to be tapped, metric

1...28 mm

Pitch limit of threads to be cut, inch

28-1 threads per inch

Spindle speed spindle speed

8...355

Maximum spindle torque, Nm

3000

Main engine power

15 kW

Speed control

Step,

Spindle bore diameter

340 mm

Chuck diameter

Ø720 (Ø630* optional) mm

Chuck type

Mechanized

Cutter section

4 pcs

Cutter section

32x32 mm

Turning mechanism

Manual

Moving the tailstock quill

240 mm

Diameter of tailstock quill

120 mm

Tailstock quill taper

Morse 6

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
