Miniature Solid State Relay REM-MSV5DC for Power Switching Applications

Miniature solid-state (semiconductor) relay REM-MSV5DC, RBNM.647611.001TU is designed to provide switching of the output power circuit according to the closing contact scheme at the control input voltage of 5 V DC. Modes (categories) of application according to GOST IEC 60947-1-2017: AC-1 (non-inductive or weakly inductive loads, resistance furnaces); AC-15 (control of electromagnetic AC loads). Number and type of contacts - 1NO.

Provides switching circuit 230 V AC with load current up to 2 A without zero detector. Possibility of soldering to the printed circuit board.
