CNC Vertical Lathe Machine Model 1M532F4 for Metal Processing

Available for Import

CNC Vertical Lathe Machine Model 1M532F4 for Precision Metal Processing

Multi-Function Metal Machines

Manufacturer: STANKOTECH OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

VBL1600 CNC Single Standing Centre Centre Lathe VBL2000 CNC Single Standing Centre Centre Lathe Double column CNC lathe-carousel machine of model 1M540F4 CNC

Description

The machine lathe-carousel two-stand CNC model 1M532F4 CNC is designed for roughing and finishing machining of parts made of cast iron, steel, non-ferrous metals and their alloys, namely: processing of internal, external and end surfaces of rotation of simple and complex shapes, as well as cutting threads or screw grooves on surfaces coaxial to the axis of rotation of the faceplate

Specifications

Largest diameter of the workpiece to be machined

3200 mm

Maximum height of the workpiece to be machined

1600 mm

Maximum weight of the workpiece to be machined

25000 kg

Table face diameter

2800 mm

Maximum torque on the faceplate, kNm

125

Power output of the electric motor of the main motion of the faceplate

2x40 kW

Maximum cross member displacement

1200 mm

Crossbar travel speed, mm/min

400
