CNC Lathe Machine RT817F3-5 Available for Import

CNC Lathe Machine RT817F3-5 for Precision Machining Applications

CNC Metal Lathes
Manufacturer: RSZ LLC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Available Models

CNC lathe model RT817F3-3 CNC lathe model RT817F3-8 CNC lathe model RT817F3-12

Description

The lathe with CNC model RT817F3-5, distance between centres 5000mm, is designed for machining in the chuck and in the centres of parts with rectangular, stepped and curved profiles, as well as for threading. Technical characteristics and rigidity of the machine allow to fully use the capabilities of high-speed cutting and carbide tools for processing of both ferrous and non-ferrous metals. Accuracy class P according to GOST 8-82. Warranty period of operation is 12 months.

Specifications

Type of product according to PP RF 616
Universal lathes and screw-cutting machines, with CNC, CNC)
Width
3200 mm
Height
2250 mm
Machine weight, not more
14200 kg
Length
8800 mm
Distance between centers
5000 mm
Maximum length of the workpiece to be processed, not less than
3000 mm
The largest diameter of the workpiece above the bed, not less than
1000 mm
The largest diameter of the workpiece to be machined above the slide, not less than
650 mm
The largest diameter of the workpiece to be installed above the bed, not less than
1000 mm
Save Your Time

Share your requirements for a quick response!

Instant response in 15 minutes
Best wholesale prices guaranteed
Direct from manufacturer

Delivery & Payment

Shipping Terms

FOB Novorossiysk, Russia CIF Available to major ports worldwide EXW Manufacturer's facility, Russia

Delivery Time

Sea freight: 30-60 days (depending on destination) Air freight: 14-21 days (for urgent orders)

Payment Methods

Letter of Credit (L/C) Wire Transfer (T/T) Escrow Services
