Vector Network Analyzer R4213/2 for S-Parameter and Reflection Coefficient Measurements

The vector circuit analyser R4213/2 is designed for measurements in laboratory conditions of complex transmission and reflection coefficients (S parameters) of two-pole and four-pole circuits. The analyser uses a coaxial output connector type N socket according to GOST RV 51914. Measurement of the matrix S parameters is carried out in one connection of the device under investigation.

Field of application - production and control of RF and microwave equipment and devices, research, adjustment and testing of ultra-high frequency units used in radio electronics, communications, instrumentation, measuring equipment. The analyser functions together with a personal computer via a standard Ethernet interface. The operating frequency range is from 0.3 to 13500 MHz.
