Portable Explosive Detector with Built-in Radiometer DIANON for Safety Applications

Gas and Smoke Analysers

Manufacturer: DIAGNOSTIKA-M LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

"Dianon" is a new unique development of TSNK company, which combines two products at once: a portable fast-acting highly sensitive detector, which allows to detect and identify explosives both in the form of vapours and particles (traces) and a search radiometer, which allows to detect and localise sources of ionising gamma radiation.

The built-in radiometer allows estimation of the radiation dose rate, indication of the maximum value of the dose rate during operation, as well as indication of the accumulated radiation dose during operation of the device. The working exposure time of the Dianon radiometer is only 1 second, which is an undeniable advantage of this product over competitors.

The instrument is based on advanced technology, which is based on the principle of non-linear dependence of ion mobility on electric field strength. The corona discharge principle is used for ionisation of sample molecules.

The device does not require special

Specifications

Sensitivity of radiation registration with energy 662kEv (Cs-137) by the built-in detector, imp./(µR/hour) (in radiometer mode)

Carrier gas

Not required

Exposure dose rate measurement range, mR/h (in radiometer mode)

0÷50

Measurement error of exposure dose rate in the range 30..3000kEV, % (in radiometer mode)

less than 30 %

Energy range of registered photon radiation, keV (in radiometer mode)

30 to 3000

Storage conditions

Temperature : -30°C...+50°C Relative humidity 98% (at +25°C)

Working conditions

Temperature - -20°C...+50°C Relative humidity 95% (at +25°C)

Power supply

less than 15 watts (Search and Identification modes), less than 22 watts (Wipe mode) W

Overall dimensions of the detector, mm (L x W x H)

400x160x110 mm

Weight with battery installed

2.5 kg

"Hot" battery replacement

possible

Probability of false alarms

Less than 1 per cent (in Identification and Wipe modes) %

Saving analysis history in the detector memory

Check: date, time, type of detected material

Quiet mode

Got it

Battery discharge indication

Yes, display on display

BB detection warning signal

Audio and visual indication; In "Identification" and "Wipe" modes - indication on the display of the type of the detected substance

Possibility of connection to an external computer (PC, Mac)

Ethernet or Wi-Fi. No special software installation required.

Display

Colour, touch (resistive) 4.3"

Battery operation time (installed on the device)

240 min (without heating module) 120 min (with heating module)

Calibration

Automatic

Detection time

In "Search" mode, less than 2 seconds; In "Identification" and "Wipe" modes, less than 8 seconds.

Types of substances to be detected

TNT, TEN*, RDX* (hexogen), DNT, nitroglycerine, ammonium nitrate + diesel fuel mixture* (ANFO), EGDN, HMX*, Tetril*, gunpowder mixture*, ammonium nitrate, urea nitrate and others.

Threshold sensitivity to TNT (at temperature 20°C and humidity 80% )

10-14 g/cm3 (1 ppt) - in vapour analysis mode, 100 picograms - in trace analysis mode

Ionisation source

Corona discharge

Technology

Ion mobility incremental ion mobility spectrometry (FAIMS)

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
