Multifunctional Technical Complex KTSM-02 for Automatic Rail Monitoring

The complex of technical means multifunctional KTSM-02 is designed for automatic control of technical condition of railway rolling stock on the train running. In accordance with the project KTSM-02 can be equipped with control subsystems for various purposes: wagon axle units (B05, BN-05, B90), locomotive axle units (L05), braked wheelsets (T05), wheel defects control subsystem (K), subsystem for detection of dragging parts (UKSPS). The KTSM-02 complex includes an instrument rack, BSC-1 unit (protection devices, emergency relay, UKP-220M device), PK-05 unit (VIP module, MCMC module, PT module, MDS module, MUPK module, MGR-M module, MFDO module, MFRC module), BUNK unit (ICC module, MIP module, MKK module), KNM-05 (KNM-05-01) chamber, DTNV-2 (3) sensor in aspiration container, calibrator IN7.375.000; axis counting sensor (DM-95N, PE-1), I/O unit, UPS; set of mounting accessories (junction boxes, couplings, cables).
