Disc Harrow BDM-9x4P for Efficient Soil Processing and Preparation

Disc harrow. Semi-trailed disc tillage implement. It consists of: -three welded frames (central, two wings), with welded sleeves, in which the working elements are mounted with the possibility of rotation at a limited angle.

The working element is a rigid column, a bearing unit and a spherical disc, which is directly the working element that cultivates the soil. <ul> <li>- truss, which is a welded structure, to which the centre frame, hydraulic cylinders for lifting the wings, chassis, trailed implement are attached.</li> <li>trailer hitch.</li> <li>hydroficated chassis.</li> </ul>The implement has four rows of working tools. For levelling the cultivated soil, a leveller (roller) is hinged to the frame at the rear.

The implement can be equipped with the following types of rollers: tubular, spiral or chevron rollers. The roller can be used to adjust the working depth. The width of the cultivated strip is 9m.
