Assembly block 5,0t Gp-B-5,0-0102

Material Handling Equipment

Manufacturer: SAMSON LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Available Models

Closed Type Mounting Block 0.5t GP-B-0.5-01(02) Mounting block 3,2t Gp-B-3,2-01(02)

Description

Closed type mounting blocks consist of a roller, the axis of which is located between two plates (cheeks), reinforced with pull rods, possible version of blocks: with hook, with pin.

They are used to change the direction of pull and reduce the pulling force during rigging operations. It is used in both manually and electrically driven mechanisms. .

Specifications

Payload

5 t

Designation

??-?-5,0-01(02)

Rope diameter

14,0-18,0 mm

Support pin diameter

30 mm

Product weight

19 kg

Manufacturer's item

60100040474
