125 kHz RFID Reader for Access Control Systems - Matrix-VII (mod. E H Keys) Available for Import

125 kHz RFID Reader for Access Control Systems - Matrix-VII

Electrical Interface Devices
Manufacturer: OTK LLC
Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Description

It is used in access control and management systems (ACS). The reader transmits to the controller the code of the brought identifier (card, key fob, etc.) standard E-Marine or HID ProxCardII or the code typed from the keyboard, via protocols iButton (Dallas Touch Memory) or Wiegand 26. The reader provides the ability to pass both with an identifier and without an identifier by typing a code on the keyboard.

Specifications

Operating frequency
125
Type of identifiers used
EM-Marine, HID ProxCard II
Defining the card standard
Automatic, without additional settings
Reading range
6...10 cm
Output interface
Ibutton (Dallas Touch Memory), Wiegand-26
Maximum line length from reader to controller: Dallas Touch Memory
No more than 15 m
Maximum line length from reader to controller: Wiegand
Not more than 100 m
Light and sound indication
Got it
External control of LED and sound
Got it
DC supply voltage
B1/B8 2100/900 MHz V
Maximum current consumption
150 mA
Dimensions
106x86x33 mm
Housing material
ABS plastic
Operating temperature
-40...50 °C

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
