Mineral Fertilizer Spreader RA-3000 "Grach Max" for Efficient Fertilization

Fertiliser Spreading Equipment

Manufacturer: ROSTSELMASH OJSC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

The spreader is used for spreading dry, granular, prilled and crystalline fertiliser, seed and slug repellent. The spreader is designed for use in all soil and climatic zones. The spreader is coupled with tractors of 14 kN (1.4 t.s.) class at PTO rotation speed n=540 rpm.

Hopper capacity is 3000 litres.

Specifications

Type of product according to PP RF 616

Organic and mineral fertilizer spreaders

Capacity per hour

19...54

Height

2750 mm

Width

2580 mm

Length

2985 mm

Operating speed

8...15

Weight

1170 kg

Working width

24...36 m

Fertiliser spreading

centrifugal

Transport speed, not more

Weight of loaded spreader

4170 kg

Tractor PTO speed

540

Number of disc revolutions

730

Power consumption, max.

16.9 kW

Number of spreader discs

2 pcs

Hopper capacity

Ground clearance

315 mm

Tractor track width, not less than

1850 mm

MTBF for failure of complexity group II of a single product, not less than

120

Fertiliser application rate

100...1000

Deviation of the actual application dose from the preset dose, not more than

8 %

Unevenness of fertiliser distribution along the movement, not more than

7 %

Unevenness of fertiliser distribution during main fertiliser application at the working width for granular fertiliser

20 %

Uneven distribution of fertiliser at basic fertiliser application over the working width for powdered fertiliser

25 %

Service personnel

Service life

8 year

Shift time utilisation factor

0.74

Process availability factor

0.98

Readiness factor

0.97

Note: All specifications are provided by the manufacturer and may be subject to change. Please contact us to confirm the latest specifications before placing your order.
