Drainage Protection Stations SDZ.PTM and SDZU.PTM for Underground Protection

Static Power Converters

Manufacturer: PROMTEHMASTER LLC

Price: Request Quote

Bulk pricing available

FOB, CIF & EXW terms available

Email Inquiry

Description

Drainage protection stations of SDZ.PTM and SDZU.PTM types are designed to protect underground structures from constant stray current of electrified rail transport by changing the current distribution in the system "rail - ground - underground structure", as well as to reduce the impact of electromagnetic radiation from high-voltage sources. Drains correspond to types of climatic execution U, UHL or XL with categories of placement 1 or 2 according to GOST 15150.

Specifications

Rated output current in cathodic protection mode

100...500 A

Rated active power output

5 kW

Power factor in rated mode

0,9

Efficiency factor

85 %

Degree of protection (IP)

For placement category 1 according to GOST 15150 - not lower than IP34; For placement category 2 according to GOST 15150 - not lower than IP20.

AC input voltage

230 V

Remote monitoring

Digital interface RS-485, Modbus RTU protocol, GSM/GPRS

Earthquake-proof version according to MSK-64 scale

10 points
